Crop chopper
Introduction of Crop Chopper Machine
The crop chopper machine conveys the material to be processed to the mashing chamber through a conveyor, and the material is mashed by the interaction between the high turret and the slab, and the smashed material is thrown outside by the throwing blade.
Working Principle of Crop Chopper
This machine adopts multi-knife cutting principle, can make various straw, fresh straw and bark into ideal demand according to demand, processing speed is 4-5 tons per hour, supporting power 15KW, voltage 380V, we are manufacturing large sraw chopper machineThe technical aspects of the silk machine make the previous deficiencies perfect.
After half a year of repeated experiments and practical operations, our factory finally solved this technical problem. This machine is a necessary opportunity for breeding professional households, and it is also an indispensable raw material production machine for fuel ethanol production. The silk reeling machine produced by our factory has occupied the vast market in crushing technology by virtue of its high quality, high efficiency and energy saving.
Application of Crop Chopper Machine
The crop chopper is suitable for the stalk processing of cotton stalks, corn stalks, wheat straw and other crop stalks and bark. The product can crush various crop straws to about 20-100mm, and is applied to the fields of paper making, breeding, straw power generation and the like. The material that has been machined is soft and has no induration, and the palatability of the livestock is improved, so that the feed utilization rate is as high as 100%.
Technical Parameters of Crop Chopper Machine
| Serial number | project | unit | specification | ||
|---|---|---|---|---|---|
| 1 | Specification model | / | 9RSJ-3 | 9RSJ-6 | |
| 2 | Dimensions (length * width * height) | Mm | 2350*680*1050 | 2800*900*1200 | |
| 3 | Total Weight | Kg | 280 | 600 | |
| 4 | Motor Power | Reeling machine main motor | Kw | 7.5 | 15 |
| Feed motor (reducer) | Kw | 1.5 | 1.5 | ||
| 5 | Matching motor | Rated voltage | v | 380 | 380 |
| Rated speed | r/min | 2050 | 2050 | ||
| 6 | Straw silking rate (corn stalk) | % | ≥90 | ≥90 | |
| 7 | Working efficiency (water content 55%-65%) | t/h | 3 | 6 | |
| 8 | Silk length | Mm | 20-40 | 20-40 | |
| 9 | Spray distance | m | 3-6 | 10-15 | |
Crop Chopper Machine Working Performance
| Performance | Index | ||||
|---|---|---|---|---|---|
| Production efficiency (t/h) | Corn stalks | Cotton stalk | Straw | straw | Bark |
| 2-5 | 5-8 | 2-3 | 3-4 | 2-4 | |
| Grass distance (m) | 10-15 | ||||
